Boardoza TUSB8041 Four-Port USB 3.0 Hub Breakout Board
Boardoza TUSB8041 USB Hub Board is a high-performance USB expansion solution that provides four USB Type-A ports from a single USB Type-C upstream connection. Based on the Texas Instruments TUSB8041, the board supports USB 3.0 SuperSpeed data transfer up to 5 Gbps while remaining fully backward compatible with USB 2.0 and USB 1.1 devices. It operates out of the box without any programming or configuration, making it ideal for embedded systems, industrial applications, and development platforms requiring reliable high-speed USB connectivity.
1 / 2
Key Features
- TUSB8041 based 4-port USB 3.0 hub controller
- 1× USB Type-C upstream and 4× USB Type-A downstream ports
- USB 3.0 SuperSpeed data transfer up to 5 Gbps
- Backward compatible with USB 2.0 and USB 1.1 devices
- Plug-and-play operation with no programming required
- Automatic speed negotiation based on host capabilities
- Per-port or ganged power management support
- Integrated over-current monitoring and power control
- Suitable for industrial, embedded, and development applications
Technical Specifications
- Item
- TUSB8041 USB Hub
- Input Voltage
- USB Type-C
- Functions
- USB 3.0 Hub and Peripheral Expansion
- USB Standart
- USB 3.0 / USB 2.0 / USB 1.1 compatible
- Maximum Data Rate
- Up to 5 Gbps
- Number of Downstream Ports
- 4
- Operating Temperature
- 0°C / +70°C
- Board Dimensions
- 79.135mm x 39mm
Support
For technical questions, documentation and issue reports, use the GitHub repository or write to us directly.
